KVM-RB-20MKH(T)

  • Item：AV over IP Extender
  • Spec.：1080P/HDMI/USB/Audio/RS232/IR CAT5e KVM Extender 150M with Fiber
Features
  • Resolution up to 1080p@60Hz & 1920 x 1200px.
  • Signal extension up to 150M over CAT5e (or greater) cable.
  • workable with Ethernet switches for HDMI® extension, distribtuion, switching, and matrix.
  • Built-in loop-out port for extra local HDMI® display at TX side.
  • Built-in 4 USB ports for keyboard, mouse, flash drive...etc.
  • Supports up to 8 x 16 video wall.
  • Supports HDMI® audio embedding and extraction function.
  • Supports USB, full-duplex RS232, bi-directional IR, analog audio transmission.
  • Supports RS232 signal distribution.
  • Managed via Windows based software, Android/iOS APP, Web GUI, IR remote, panel pushbutton, Telnet API, RS232 console.
    Inquiry
    Inquiry List
    Includes
    • KVM-RB-20MKH(T) x 1
    Specification
    ITEM NO.
    KVM-RB-20MKH(T)
    Compliance
    HDMI 1.4 , HDCP 1.4, USB 2.0/ 1.1/ 1.0
    Max. Video Resolution
    4K@30Hz
    Max. Transmission Distance
    120M over CAT5e; 140M over CAT6; 60KM over single mode fiber optic
    Audio Format
    LPCM7.1@192KHZ
    RS232 Baud Rate
    115200 bps
    IR Support
    20-60kHz , ±45°, 5M
    Video Input
    1 x HDMI Type A / 1 x RJ45, 1 x SFP
    Video Output
    1 x RJ45, 1 x SFP / 1 x HDMI Type A
    Video Loop-out
    1 x HDMI Type A / -
    Analog Audio Input
    1 x (3.5mm) Stereo Phone Jack / 1 x (3.5mm) Mono Phone Jack
    Analog Audio Output
    1 x (3.5mm) Stereo Phone Jack / 1 x (3.5mm) Stereo Phone Jack
    IR Receiver
    -/1 x (3.5mm) Stereo Phone Jack
    IR Emitter
    1 x (3.5mm) Stereo Phone Jack /-
    RS232 Interface
    1 x DB9 Female / 1 x DB9 Male
    USB Interface
    1 x USB Type B / 4 x USB Type A
    Power Supply
    DC 5V 2A / DC 5V 2A
    Power Consumption
    1200mA / 400mA
    Operation
    0 ~ 55℃
    Storage
    -20 ~ 85℃
    Humidity
    Up to 95%
    Dimension
    125 x 140 x 30mm / 125 x 140 x 30mm
    Weigh
    380g / 380g
    Notice
    • Do not expose in moist environment, this product is not waterproof, make sure to install location.
    • Please handle with care, this product contains highly precision components.
    ※Specifications and product designs are subject to change without notice.
